911 Industrial Mortar Spraying Machine – Flagship High-Volume Wall Plaster Sprayer
Product Specs
Output Capacity: 8 m³/h
Motor Power: 11 kW
Max Horizontal Conveying: 60 m
The AK- 911 Industrial Mortar Spraying Machine is the flagship wall plaster sprayer, engineered for maximum-volume, continuous application of cement mortar, gypsum, and lime-based renders on large interior and exterior surfaces. Powered by an 11 kW motor and an oversized screw pump, it delivers a class-leading 8 m³/h output, reducing manual plastering time by up to 85% while achieving a dense, uniform, bubble-free finish.
With a 60 m horizontal and 40 m vertical conveying range, a 100 L stainless-steel hopper, and an advanced electric control panel, the 911 is built for non-stop production on major infrastructure and industrial projects. It handles aggregates up to 12 mm and serves high-rise towers, tunnels, and large-scale commercial developments. Heavy-duty, dust-controlled, and designed for fast servicing, it minimizes labor costs and material waste on the most demanding jobsites.
| Model: AK-911 |
| Output Capacity: 8 m³/h |
| Motor Power: 11 kW |
| Voltage / Frequency: 380 V / 50 Hz |
| Max Aggregate Size: 12 mm |
| Max Horizontal Conveying: 60 m |
| Max Vertical Conveying: 40 m |
| Hopper Capacity: 100 L |
| Hose Inner Diameter: 51 mm |
| Working Pressure: 5 MPa |
| Machine Weight: 320 kg |
| Dimensions (L×W×H): 1700 × 800 × 1300 mm |
| Applicable Materials: Cement mortar / gypsum / lime-based |
| Hose Length: 50 m |
| Control Mode: Advanced panel with pressure display |
| Cooling Method: Air-cooled |
| Crew Requirement: 4–5 persons |
